JANS1N5809 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: B, Axial
- Description: DIODE GEN PURP 100V 3A AXIAL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANS1N5809 Specifications:
- Manufacturer Product Number: JANS1N5809
- Mfr: Microchip Technology
- Detailed Description: DIODE GEN PURP 100V 3A AXIAL
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/477
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io): 3A
- Voltage - Forward (Vf) (Max) @ If: 875 mV @ 4 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 30 ns
- Current - Reverse Leakage @ Vr: 5 µA @ 100 V
- Capacitance @ Vr, F: 60pF @ 10V, 1MHz
- Mounting Type: Through Hole
- Package / Case: B, Axial
- Operating Temperature - Junction: -65°C ~ 175°C
- JANS1N5809 Microchip, DIODE GEN PURP 100V 3A AXIAL, Discrete Semiconductor Products~Diodes - Rectifiers - Single
