APT25GR120B Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 75A 521W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT25GR120B Specifications:
- MfrPart.: APT25GR120B
- Mfr: Microchip Technology
- Description: IGBT 1200V 75A 521W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 75 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 3.2V @ 15V, 25A
- Power-Max: 521 W
- SwitchingEnergy: 742µJ (on), 427µJ (off)
- InputType: Standard
- GateCharge: 203 nC
- Td(on/off)@25°C: 16ns/122ns
- TestCondition: 600V, 25A, 4.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- APT25GR120B Microchip, IGBT 1200V 75A 521W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT25GR120B, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
