APTMC120AM25CT3AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SP3
- Description: MOSFET 2N-CH 1200V 105A SP3F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APTMC120AM25CT3AG Specifications:
- MfrPart.: APTMC120AM25CT3AG
- Mfr: Microchip Technology
- Description: MOSFET 2N-CH 1200V 105A SP3F
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 1200V (1.2kV)
- Current-ContinuousDrain(Id)@25°C: 113A (Tc)
- RdsOn(Max)@IdVgs: 25mOhm @ 80A, 20V
- Vgs(th)(Max)@Id: 2.2V @ 4mA (Typ)
- GateCharge(Qg)(Max)@Vgs: 197nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 3800pF @ 1000V
- Power-Max: 500W
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SP3
- APTMC120AM25CT3AG Microchip, MOSFET 2N-CH 1200V 105A SP3F, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
APTMC120AM25CT3AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
