JAN2N3716 Microchip TRANS NPN 80V 10A TO-3
JAN2N3716 Images
JAN2N3716 Images
JAN2N3716
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-3
  • Description: TRANS NPN 80V 10A TO-3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
JAN2N3716 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
JAN2N3716 Specifications:
  • MfrPart.: JAN2N3716
  • Mfr: Microchip Technology
  • Description: TRANS NPN 80V 10A TO-3
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: Military, MIL-PRF-19500/408
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 10 A
  • Voltage-CollectorEmitterBreakdown(Max): 80 V
  • VceSaturation(Max)@IbIc: 2.5V @ 2A, 10A
  • Current-CollectorCutoff(Max): 1mA
  • DCCurrentGain(hFE)(Min)@IcVce: 30 @ 3A, 2V
  • Power-Max: 5 W
  • Frequency-Transition: -
  • OperatingTemperature: -65°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-3
  • JAN2N3716 Microchip, TRANS NPN 80V 10A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
