APT35GP120B2D2G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT PT COMBI 1200V 35A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT35GP120B2D2G Specifications:
- MfrPart.: APT35GP120B2D2G
- Mfr: Microchip Technology
- Description: IGBT PT COMBI 1200V 35A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: POWER MOS 7®
- PartStatus: Active
- IGBTType: PT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 96 A
- Current-CollectorPulsed(Icm): 140 A
- Vce(on)(Max)@VgeIc: 3.9V @ 15V, 35A
- Power-Max: 540 W
- SwitchingEnergy: 1mJ (on), 1.185mJ (off)
- InputType: Standard
- GateCharge: 150 nC
- Td(on/off)@25°C: 14ns, 99ns
- TestCondition: 800V, 35A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- APT35GP120B2D2G Microchip, IGBT PT COMBI 1200V 35A TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
APT35GP120B2D2G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
