APT40N60JCU3 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-227
- Description: MOSFET N-CH 600V 40A SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
APT40N60JCU3 Specifications:
- MfrPart.: APT40N60JCU3
- Mfr: Microchip Technology
- Description: MOSFET N-CH 600V 40A SOT227
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 70mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 3.9V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 259 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7015 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 290W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SOT-227
- APT40N60JCU3 Microchip, MOSFET N-CH 600V 40A SOT227, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
APT40N60JCU3, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
