2N2222AE3 Microchip SMALL-SIGNAL BJT
2N2222AE3 Images
2N2222AE3 Images
2N2222AE3
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-206AA, TO-18-3 Metal Can
  • Description: SMALL-SIGNAL BJT
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
2N2222AE3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
2N2222AE3 Specifications:
  • MfrPart.: 2N2222AE3
  • Mfr: Microchip Technology
  • Description: SMALL-SIGNAL BJT
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 800 mA
  • Voltage-CollectorEmitterBreakdown(Max): 50 V
  • VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 50nA
  • DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
  • Power-Max: 500 mW
  • Frequency-Transition: -
  • OperatingTemperature: -65°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-206AA, TO-18-3 Metal Can
  • 2N2222AE3 Microchip, SMALL-SIGNAL BJT, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
