MCP14700-E/MF Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-VDFN Exposed Pad
- Description: IC GATE DRVR HALF-BRIDGE 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCP14700-E/MF Specifications:
- MfrPart.: MCP14700-E/MF
- Mfr: Microchip Technology
- Description: IC GATE DRVR HALF-BRIDGE 8DFN
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel MOSFET
- Voltage-Supply: 4.5V ~ 5.5V
- LogicVoltage-VILVIH: -
- Current-PeakOutput(SourceSink): 2A, 2A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 36 V
- Rise/FallTime(Typ): 10ns, 10ns
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-VDFN Exposed Pad
- MCP14700-E/MF Microchip, IC GATE DRVR HALF-BRIDGE 8DFN, Integrated Circuits (ICs)~PMIC - Gate Drivers
