USD545E3 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AB, DO-5, Stud
- Description: DIODE POWER SCHOTTKY
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
USD545E3 Specifications:
- Manufacturer Product Number: USD545E3
- Mfr: Microchip Technology
- Detailed Description: DIODE POWER SCHOTTKY
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 45 V
- Current - Average Rectified (Io): 75A
- Voltage - Forward (Vf) (Max) @ If: 680 mV @ 60 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 20 mA @ 45 V
- Capacitance @ Vr, F: -
- Mounting Type: Stud Mount
- Package / Case: DO-203AB, DO-5, Stud
- Operating Temperature - Junction: -55°C ~ 175°C
- USD545E3 Microchip, DIODE POWER SCHOTTKY, Discrete Semiconductor Products~Diodes - Rectifiers - Single
USD545E3, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
