USD545 Microchip RECTIFIER
USD545 Images
USD545 Images
USD545
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-203AB, DO-5, Stud
  • Description: RECTIFIER
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
USD545 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
USD545 Specifications:
  • Manufacturer Product Number: USD545
  • Mfr: Microchip Technology
  • Detailed Description: RECTIFIER
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Bulk
  • Series: -
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 45 V
  • Current - Average Rectified (Io): 75A
  • Voltage - Forward (Vf) (Max) @ If: 680 mV @ 60 A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): -
  • Current - Reverse Leakage @ Vr: 20 mA @ 45 V
  • Capacitance @ Vr, F: -
  • Mounting Type: Stud Mount
  • Package / Case: DO-203AB, DO-5, Stud
  • Operating Temperature - Junction: 175°C (Max)
  • USD545 Microchip, RECTIFIER, Discrete Semiconductor Products~Diodes - Rectifiers - Single
