U6820BM-MFPG3 Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC DRIVER BCDMOS DUAL/QD 16-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
U6820BM-MFPG3 Specifications:
- MfrPart.: U6820BM-MFPG3
- Mfr: Microchip Technology
- Description: IC DRIVER BCDMOS DUAL/QD 16-SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge (4)
- Applications: General Purpose
- Interface: SPI
- LoadType: Inductive
- Technology: BCDMOS
- RdsOn(Typ): 4Ohm LS, 6.25Ohm HS
- Current-Output/Channel: -
- Current-PeakOutput: 50mA
- Voltage-Supply: 4.5V ~ 5.5V
- Voltage-Load: 6V ~ 18V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Auto Restart, Status Flag
- FaultProtection: Current Limiting, ESD, Short Circuit, Over Temperature, Over Voltage, UVLO
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- U6820BM-MFPG3 Microchip, IC DRIVER BCDMOS DUAL/QD 16-SOIC, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
U6820BM-MFPG3, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
