U6815BM-NFLG3 Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers SupplierDevicePackage: 28-SO
- Description: IC PWR DRIVER N/P-CHAN 0.05 28SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
U6815BM-NFLG3 Specifications:
- MfrPart.: U6815BM-NFLG3
- Mfr: Microchip Technology
- Description: IC PWR DRIVER N/P-CHAN 0.05 28SO
- Product Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchType: General Purpose
- NumberofOutputs: 12
- Ratio-Input:Output: 1:12
- OutputConfiguration: High Side or Low Side
- OutputType: N/P-Channel
- Interface: SPI
- Voltage-Load: 40V (Max)
- Voltage-Supply(Vcc/Vdd): 4.5V ~ 5.5V
- Current-Output(Max): 600mA
- RdsOn(Typ): 2Ohm (Max), 1.5Ohm (Max)
- InputType: -
- Features: -
- FaultProtection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 28-SO
- U6815BM-NFLG3 Microchip, IC PWR DRIVER N/P-CHAN 0.05 28SO, Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
U6815BM-NFLG3, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
