TN2501N8-G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-243AA (SOT-89)
- Description: MOSFET N-CH 18V 400MA TO243AA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TN2501N8-G Specifications:
- MfrPart.: TN2501N8-G
- Mfr: Microchip Technology
- Description: MOSFET N-CH 18V 400MA TO243AA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 18 V
- Current-ContinuousDrain(Id)@25°C: 400mA (Tj)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.2V, 3V
- RdsOn(Max)@IdVgs: 2.5Ohm @ 200mA, 3V
- Vgs(th)(Max)@Id: 1V @ 1mA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 110 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 1.6W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-243AA (SOT-89)
- TN2501N8-G Microchip, MOSFET N-CH 18V 400MA TO243AA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
