TN0604N3-G Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-92-3
- Description: MOSFET N-CH 40V 700MA TO92-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TN0604N3-G Specifications:
- MfrPart.: TN0604N3-G
- Mfr: Microchip Technology
- Description: MOSFET N-CH 40V 700MA TO92-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 700mA (Tj)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 750mOhm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 1.6V @ 1mA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 190 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 740mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-92-3
- TN0604N3-G Microchip, MOSFET N-CH 40V 700MA TO92-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
TN0604N3-G, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
