TCM680CPA Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC REG CHARG PUMP INV DL 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCM680CPA Specifications:
- MfrPart.: TCM680CPA
- Mfr: Microchip Technology
- Description: IC REG CHARG PUMP INV DL 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
- Package: Tube
- Series: -
- PartStatus: Obsolete
- Function: Ratiometric
- OutputConfiguration: Positive and Negative (Dual Rail)
- Topology: Charge Pump
- OutputType: Fixed
- NumberofOutputs: 2
- Voltage-Input(Min): 2V
- Voltage-Input(Max): 5.5V
- Voltage-Output(Min/Fixed): -Vin, 2Vin
- Voltage-Output(Max): -
- Current-Output: 10mA
- Frequency-Switching: 21kHz
- SynchronousRectifier: No
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- TCM680CPA Microchip, IC REG CHARG PUMP INV DL 8DIP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
TCM680CPA, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
