TC4424VMF Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-VDFN Exposed Pad
- Description: IC GATE DRVR LOW-SIDE 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TC4424VMF Specifications:
- MfrPart.: TC4424VMF
- Mfr: Microchip Technology
- Description: IC GATE DRVR LOW-SIDE 8DFN
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Low-Side
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel, P-Channel MOSFET
- Voltage-Supply: 4.5V ~ 18V
- LogicVoltage-VILVIH: 0.8V, 2.4V
- Current-PeakOutput(SourceSink): 3A, 3A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 23ns, 25ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-VDFN Exposed Pad
- TC4424VMF Microchip, IC GATE DRVR LOW-SIDE 8DFN, Integrated Circuits (ICs)~PMIC - Gate Drivers
TC4424VMF, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
