SM05/TR7 Images
- Manufacturer: Microchip
- Category: Circuit Protection~TVS - Diodes Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: TVS DIODE 5VWM 9.8VC SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SM05/TR7 Specifications:
- MfrPart.: SM05/TR7
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: TVS DIODE 5VWM 9.8VC SOT23-3
- Product Category: Circuit Protection~TVS - Diodes
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- Type: Zener
- UnidirectionalChannels: 2
- BidirectionalChannels: 1
- Voltage-ReverseStandoff(Typ): 5V
- Voltage-Breakdown(Min): 6V
- Voltage-Clamping(Max)@Ipp: 9.8V
- Current-PeakPulse(10/1000µs): 5A (8/20µs)
- Power-PeakPulse: 300W
- PowerLineProtection: No
- Applications: General Purpose
- Capacitance@Frequency: 400pF @ 1MHz, 200pF @ 1MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- SM05/TR7 Microchip, TVS DIODE 5VWM 9.8VC SOT23-3, Circuit Protection~TVS - Diodes
SM05/TR7, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
