SG7815AL Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 20-CLCC
- Description: IC REG LINEAR 15V 1.5A 20CLCC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG7815AL Specifications:
- MfrPart.: SG7815AL
- Mfr: Microchip Technology
- Description: IC REG LINEAR 15V 1.5A 20CLCC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tray
- Series: Military, MIL-STD-883
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 1
- Voltage-Input(Max): 50V
- Voltage-Output(Min/Fixed): 15V
- Voltage-Output(Max): -
- VoltageDropout(Max): 2.5V @ 500mA
- Current-Output: 1.5A
- Current-Quiescent(Iq): -
- Current-Supply(Max): 7 mA
- PSRR: -
- ControlFeatures: Enable
- ProtectionFeatures: Over Current, Over Temperature
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-CLCC
- SG7815AL Microchip, IC REG LINEAR 15V 1.5A 20CLCC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
SG7815AL, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
