SG2823L Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 20-CLCC
- Description: DRIVER - MEDIUM CURRENT ARRAY, H
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG2823L Specifications:
- MfrPart.: SG2823L
- Mfr: Microchip Technology
- Description: DRIVER - MEDIUM CURRENT ARRAY, H
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tray
- Series: -
- PartStatus: Active
- TransistorType: 8 NPN Darlington
- Current-Collector(Ic)(Max): 500mA
- Voltage-CollectorEmitterBreakdown(Max): 95V
- VceSaturation(Max)@IbIc: 1.6V @ 500µA, 350mA
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: -
- Power-Max: -
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-CLCC
- SG2823L Microchip, DRIVER - MEDIUM CURRENT ARRAY, H, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
