SG2003J Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: TRANS 7NPN DARL 50V 0.5A 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG2003J Specifications:
- MfrPart.: SG2003J
- Mfr: Microchip Technology
- Description: TRANS 7NPN DARL 50V 0.5A 16DIP
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: 7 NPN Darlington
- Current-Collector(Ic)(Max): 500mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- VceSaturation(Max)@IbIc: 1.6V @ 500µA, 350mA
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 350mA, 2V
- Power-Max: -
- Frequency-Transition: -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- SG2003J Microchip, TRANS 7NPN DARL 50V 0.5A 16DIP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
