SG1644J Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-CDIP (0.300, 7.62mm)
- Description: HALF BRIDGE DRIVER, NON-INVERTIN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG1644J Specifications:
- MfrPart.: SG1644J
- Mfr: Microchip Technology
- Description: HALF BRIDGE DRIVER, NON-INVERTIN
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: Military, MIL-STD-883
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel MOSFET
- Voltage-Supply: 4.5V ~ 20V
- LogicVoltage-VILVIH: 0.7V, 2V
- Current-PeakOutput(SourceSink): 500mA, 500mA
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 35ns, 30ns
- OperatingTemperature: -55°C ~ 125°C (TJ)
- MountingType: Through Hole
- Package/Case: 14-CDIP (0.300, 7.62mm)
- SG1644J Microchip, HALF BRIDGE DRIVER, NON-INVERTIN, Integrated Circuits (ICs)~PMIC - Gate Drivers
