SG1526BJ Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 18-CDIP (0.300, 7.62mm)
- Description: IC REG CTRLR BUCK/FLYBACK 18DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG1526BJ Specifications:
- MfrPart.: SG1526BJ
- Mfr: Microchip Technology
- Description: IC REG CTRLR BUCK/FLYBACK 18DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: -
- Series: -
- PartStatus: Discontinued at
- OutputType: Transistor Driver
- Function: Step-Down, Step-Up/Step-Down
- OutputConfiguration: Positive
- Topology: Buck, Flyback
- NumberofOutputs: 2
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 8V ~ 35V
- Frequency-Switching: 1Hz ~ 500kHz
- DutyCycle(Max): 49%
- SynchronousRectifier: Yes
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Dead Time Control, Enable, Frequency Control, Reset, Soft Start
- OperatingTemperature: -55°C ~ 125°C (TJ)
- MountingType: Through Hole
- Package/Case: 18-CDIP (0.300, 7.62mm)
- SG1526BJ Microchip, IC REG CTRLR BUCK/FLYBACK 18DIP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
SG1526BJ, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
