MSDT75-16 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Thyristors - SCRs - Modules Voltage-OffState: 1.6 kV
- Description: PWR MOD THYRISTOR 1600V 75V SM4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSDT75-16 Specifications:
- MfrPart.: MSDT75-16
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: PWR MOD THYRISTOR 1600V 75V SM4
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- Structure: Bridge, 3-Phase - SCRs/Diodes
- NumberofSCRsDiodes: 1 SCR, 6 Diodes
- Voltage-OffState: 1.6 kV
- Current-OnState(It(AV))(Max): 75 A
- Current-OnState(It(RMS))(Max): -
- Voltage-GateTrigger(Vgt)(Max): 3 V
- Current-GateTrigger(Igt)(Max): 150 mA
- Current-NonRepSurge5060Hz(Itsm): 920A @ 50Hz
- Current-Hold(Ih)(Max): -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- MSDT75-16 Microchip, PWR MOD THYRISTOR 1600V 75V SM4, Discrete Semiconductor Products~Thyristors - SCRs - Modules
MSDT75-16, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
