MSCSM70VM19C3AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: Module
- Description: PM-MOSFET-SIC-SBD~-SP3F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSCSM70VM19C3AG Specifications:
- MfrPart.: MSCSM70VM19C3AG
- Mfr: Microchip Technology
- Description: PM-MOSFET-SIC-SBD~-SP3F
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: 2 N Channel (Phase Leg)
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 700V
- Current-ContinuousDrain(Id)@25°C: 124A (Tc)
- RdsOn(Max)@IdVgs: 19mOhm @ 40A, 20V
- Vgs(th)(Max)@Id: 2.4V @ 4mA
- GateCharge(Qg)(Max)@Vgs: 215nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 4500pF @ 700V
- Power-Max: 365W (Tc)
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- MSCSM70VM19C3AG Microchip, PM-MOSFET-SIC-SBD~-SP3F, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
MSCSM70VM19C3AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
