MSCSM120TAM11CTPAG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: Module
- Description: PM-MOSFET-SIC-SBD~-SP6P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSCSM120TAM11CTPAG Specifications:
- MfrPart.: MSCSM120TAM11CTPAG
- Mfr: Microchip Technology
- Description: PM-MOSFET-SIC-SBD~-SP6P
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: 6 N-Channel (3-Phase Bridge)
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 1200V (1.2kV)
- Current-ContinuousDrain(Id)@25°C: 251A (Tc)
- RdsOn(Max)@IdVgs: 10.4mOhm @ 120A, 20V
- Vgs(th)(Max)@Id: 2.8V @ 3mA
- GateCharge(Qg)(Max)@Vgs: 696nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 9060pF @ 1000V
- Power-Max: 1.042kW (Tc)
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- MSCSM120TAM11CTPAG Microchip, PM-MOSFET-SIC-SBD~-SP6P, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
MSCSM120TAM11CTPAG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
