MSCSM120AM042CT6AG Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: Module
- Description: PM-MOSFET-SIC-SBD~-SP6C
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSCSM120AM042CT6AG Specifications:
- MfrPart.: MSCSM120AM042CT6AG
- Mfr: Microchip Technology
- Description: PM-MOSFET-SIC-SBD~-SP6C
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: 2 N Channel (Phase Leg)
- FETFeature: Silicon Carbide (SiC)
- DraintoSourceVoltage(Vdss): 1200V (1.2kV)
- Current-ContinuousDrain(Id)@25°C: 495A (Tc)
- RdsOn(Max)@IdVgs: 5.2mOhm @ 240A, 20V
- Vgs(th)(Max)@Id: 2.8V @ 6mA
- GateCharge(Qg)(Max)@Vgs: 1392nC @ 20V
- InputCapacitance(Ciss)(Max)@Vds: 18.1pF @ 1000V
- Power-Max: 2.031kW (Tc)
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- MSCSM120AM042CT6AG Microchip, PM-MOSFET-SIC-SBD~-SP6C, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
MSCSM120AM042CT6AG, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
