MSCD120-12 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: D1
- Description: DIODE MODULE 1.2KV 120A D1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSCD120-12 Specifications:
- Mfr Part: MSCD120-12
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: DIODE MODULE 1.2KV 120A D1
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Bulk
- Series: -
- Part Status: Obsolete
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200 V
- Current - Average Rectified (Io) (per Diode): 120A
- Voltage - Forward (Vf) (Max) @ If: 1.43 V @ 300 A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 6 mA @ 1200 V
- Operating Temperature - Junction: -
- Mounting Type: Chassis Mount
- Package / Case: D1
- MSCD120-12 Microchip, DIODE MODULE 1.2KV 120A D1, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
