MSC130SM120JCU2 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-227 (ISOTOP®)
- Description: TRANS SJT N-CH 1.2KV 173A SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSC130SM120JCU2 Specifications:
- MfrPart.: MSC130SM120JCU2
- Mfr: Microchip Technology
- Description: TRANS SJT N-CH 1.2KV 173A SOT227
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1.2 kV
- Current-ContinuousDrain(Id)@25°C: 173A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 16mOhm @ 80A, 20V
- Vgs(th)(Max)@Id: 2.8V @ 2mA
- GateCharge(Qg)(Max)@Vgs: 464 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 6040 pF/m @ 1000 V
- FETFeature: -
- PowerDissipation(Max): 745W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SOT-227 (ISOTOP®)
- MSC130SM120JCU2 Microchip, TRANS SJT N-CH 1.2KV 173A SOT227, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
