MSC040SMA120J Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-227 (ISOTOP®)
- Description: SICFET N-CH 1200V 53A SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSC040SMA120J Specifications:
- MfrPart.: MSC040SMA120J
- Mfr: Microchip Technology
- Description: SICFET N-CH 1200V 53A SOT227
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 53A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 50mOhm @ 40A, 20V
- Vgs(th)(Max)@Id: 2.8V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 137 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 1990 pF @ 1000 V
- FETFeature: -
- PowerDissipation(Max): 208W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Chassis Mount
- SupplierDevicePackage: SOT-227 (ISOTOP®)
- MSC040SMA120J Microchip, SICFET N-CH 1200V 53A SOT227, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
