MSC020SDA120K Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-220-2
- Description: SIC SBD 1200 V 20 A TO-220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSC020SDA120K Specifications:
- Manufacturer Product Number: MSC020SDA120K
- Mfr: Microchip Technology
- Detailed Description: SIC SBD 1200 V 20 A TO-220
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: -
- Part Status: Active
- Diode Type: Silicon Carbide Schottky
- Voltage - DC Reverse (Vr) (Max): 1200 V
- Current - Average Rectified (Io): 49A (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 20 A
- Speed: No Recovery Time > 500mA (Io)
- Reverse Recovery Time (trr): 0 ns
- Current - Reverse Leakage @ Vr: 200 µA @ 200 µA
- Capacitance @ Vr, F: 1130pF @ 1V, 1MHz
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Operating Temperature - Junction: -55°C ~ 175°C
- MSC020SDA120K Microchip, SIC SBD 1200 V 20 A TO-220, Discrete Semiconductor Products~Diodes - Rectifiers - Single
MSC020SDA120K, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
