MIC3809YM Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: IC REG CTRLR MULT TOPOLOGY 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MIC3809YM Specifications:
- MfrPart.: MIC3809YM
- Mfr: Microchip Technology
- Description: IC REG CTRLR MULT TOPOLOGY 8SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tube
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up/Step-Down
- OutputConfiguration: Positive, Isolation Capable
- Topology: Full-Bridge, Half-Bridge, Push-Pull
- NumberofOutputs: 1
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 2V ~ 14V
- Frequency-Switching: 200kHz
- DutyCycle(Max): 49%
- SynchronousRectifier: No
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Frequency Control
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- MIC3809YM Microchip, IC REG CTRLR MULT TOPOLOGY 8SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
MIC3809YM, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
