MCP14A1202-E/MS Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
- Description: IC GATE DRVR LOW-SIDE 8MSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCP14A1202-E/MS Specifications:
- MfrPart.: MCP14A1202-E/MS
- Mfr: Microchip Technology
- Description: IC GATE DRVR LOW-SIDE 8MSOP
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Low-Side
- ChannelType: Single
- NumberofDrivers: 1
- GateType: IGBT, N-Channel, P-Channel MOSFET
- Voltage-Supply: 4.5V ~ 18V
- LogicVoltage-VILVIH: 0.8V, 2V
- Current-PeakOutput(SourceSink): 12A, 12A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 25ns, 25ns
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
- MCP14A1202-E/MS Microchip, IC GATE DRVR LOW-SIDE 8MSOP, Integrated Circuits (ICs)~PMIC - Gate Drivers
