MCP14A0305-E/MNY Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-WFDFN Exposed Pad
- Description: IC GATE DRVR HI/LOW SIDE 8TDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCP14A0305-E/MNY Specifications:
- MfrPart.: MCP14A0305-E/MNY
- Mfr: Microchip Technology
- Description: IC GATE DRVR HI/LOW SIDE 8TDFN
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT
- Voltage-Supply: 4.5V ~ 18V
- LogicVoltage-VILVIH: 0.8V, 2V
- Current-PeakOutput(SourceSink): 3A, 3A
- InputType: Inverting, Non-Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 12ns, 12ns
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-WFDFN Exposed Pad
- MCP14A0305-E/MNY Microchip, IC GATE DRVR HI/LOW SIDE 8TDFN, Integrated Circuits (ICs)~PMIC - Gate Drivers
