MCP14A0151T-E/CH Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: SOT-23-6
- Description: IC GATE DRVR HI/LOW SIDE SOT23-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCP14A0151T-E/CH Specifications:
- MfrPart.: MCP14A0151T-E/CH
- Mfr: Microchip Technology
- Description: IC GATE DRVR HI/LOW SIDE SOT23-6
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Single
- NumberofDrivers: 1
- GateType: N-Channel, P-Channel MOSFET
- Voltage-Supply: 4.5V ~ 18V
- LogicVoltage-VILVIH: 0.8V, 2V
- Current-PeakOutput(SourceSink): 1.5A, 1.5A
- InputType: Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 11.5ns, 10ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SOT-23-6
- MCP14A0151T-E/CH Microchip, IC GATE DRVR HI/LOW SIDE SOT23-6, Integrated Circuits (ICs)~PMIC - Gate Drivers
