LX7309ILQ Images
- Manufacturer: Microchip
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 24-TFQFN Exposed Pad
- Description: IC REG CTRLR MULT TOPOLOGY 24QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LX7309ILQ Specifications:
- MfrPart.: LX7309ILQ
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: IC REG CTRLR MULT TOPOLOGY 24QFN
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Bulk
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up, Step-Down, Step-Up/Step-Down
- OutputConfiguration: Positive, Isolation Capable
- Topology: Buck, Boost, Buck-Boost, Flyback, Forward Converter
- NumberofOutputs: 1
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 9.6V ~ 20V
- Frequency-Switching: 100kHz ~ 500kHz
- DutyCycle(Max): 50%
- SynchronousRectifier: Yes
- ClockSync: Yes
- SerialInterfaces: -
- ControlFeatures: Enable, Frequency Control, Soft Start
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 24-TFQFN Exposed Pad
- LX7309ILQ Microchip, IC REG CTRLR MULT TOPOLOGY 24QFN, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
LX7309ILQ, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
