JANTXV2N6059 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-3
- Description: TRANS NPN DARL 100V 12A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTXV2N6059 Specifications:
- MfrPart.: JANTXV2N6059
- Mfr: Microchip Technology
- Description: TRANS NPN DARL 100V 12A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/502
- PartStatus: Active
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 12 A
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 3V @ 120mA, 12A
- Current-CollectorCutoff(Max): 1mA
- DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 6A, 3V
- Power-Max: 150 W
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3
- JANTXV2N6059 Microchip, TRANS NPN DARL 100V 12A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANTXV2N6059, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
