JANTX2N5685 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS NPN 60V 50A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTX2N5685 Specifications:
- MfrPart.: JANTX2N5685
- Mfr: Microchip Technology
- Description: TRANS NPN 60V 50A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/464
- PartStatus: Discontinued at
- TransistorType: NPN
- Current-Collector(Ic)(Max): 50 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 5V @ 10A, 50A
- Current-CollectorCutoff(Max): 500µA
- DCCurrentGain(hFE)(Min)@IcVce: 15 @ 25A, 2V
- Power-Max: 300 W
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-204AA, TO-3
- JANTX2N5685 Microchip, TRANS NPN 60V 50A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANTX2N5685, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
