JANTX2N5672 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS NPN 120V 30A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTX2N5672 Specifications:
- MfrPart.: JANTX2N5672
- Mfr: Microchip Technology
- Description: TRANS NPN 120V 30A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/488
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 30 A
- Voltage-CollectorEmitterBreakdown(Max): 120 V
- VceSaturation(Max)@IbIc: 5V @ 6A, 30A
- Current-CollectorCutoff(Max): 10mA
- DCCurrentGain(hFE)(Min)@IcVce: 20 @ 15A, 2V
- Power-Max: 6 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-204AA, TO-3
- JANTX2N5672 Microchip, TRANS NPN 120V 30A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANTX2N5672, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
