JANTX2N5237 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AA, TO-5-3 Metal Can
- Description: TRANS NPN 120V 10A TO-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTX2N5237 Specifications:
- MfrPart.: JANTX2N5237
- Mfr: Microchip Technology
- Description: TRANS NPN 120V 10A TO-5
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/394
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 120 V
- VceSaturation(Max)@IbIc: 2.5V @ 1A, 10A
- Current-CollectorCutoff(Max): 10µA
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 5A, 5V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-205AA, TO-5-3 Metal Can
- JANTX2N5237 Microchip, TRANS NPN 120V 10A TO-5, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
