JANTX2N3766 Microchip TRANS NPN 60V 4A
JANTX2N3766 Images
JANTX2N3766 Images
JANTX2N3766
  • Manufacturer: Microchip
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-213AA, TO-66-2
  • Description: TRANS NPN 60V 4A
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
JANTX2N3766 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
JANTX2N3766 Specifications:
  • MfrPart.: JANTX2N3766
  • Mfr: Microchip Technology
  • Description: TRANS NPN 60V 4A
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: Military, MIL-PRF-19500/518
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 4 A
  • Voltage-CollectorEmitterBreakdown(Max): 60 V
  • VceSaturation(Max)@IbIc: 2.5V @ 100mA, 1A
  • Current-CollectorCutoff(Max): 500µA
  • DCCurrentGain(hFE)(Min)@IcVce: 40 @ 500mA, 5V
  • Power-Max: 25 W
  • Frequency-Transition: -
  • OperatingTemperature: -65°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-213AA, TO-66-2
  • JANTX2N3766 Microchip, TRANS NPN 60V 4A, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
