JANTX2N3763L Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AA, TO-5-3 Metal Can
- Description: NPN TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTX2N3763L Specifications:
- MfrPart.: JANTX2N3763L
- Mfr: Microchip Technology
- Description: NPN TRANSISTOR
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/396
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 1.5 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 900mV @ 100mA, 1A
- Current-CollectorCutoff(Max): 100µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 500mA, 1V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-205AA, TO-5-3 Metal Can
- JANTX2N3763L Microchip, NPN TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANTX2N3763L, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
