JANTX2N2857 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF Package/Case: TO-72-3 Metal Can
- Description: RF TRANS NPN 15V 500MHZ TO72
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANTX2N2857 Specifications:
- MfrPart.: JANTX2N2857
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: RF TRANS NPN 15V 500MHZ TO72
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF
- Package: Bulk
- Series: Military, MIL-PRF-19500/343
- PartStatus: Obsolete
- TransistorType: NPN
- Voltage-CollectorEmitterBreakdown(Max): 15V
- Frequency-Transition: 500MHz
- NoiseFigure(dBTyp@f): 4.5dB @ 450MHz
- Gain: 12.5dB ~ 21dB @ 450MHz
- Power-Max: 200mW
- DCCurrentGain(hFE)(Min)@IcVce: 30 @ 3mA, 1V
- Current-Collector(Ic)(Max): 40mA
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-72-3 Metal Can
- JANTX2N2857 Microchip, RF TRANS NPN 15V 500MHZ TO72, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF
JANTX2N2857, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
