JANSR2N7261U Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 18-ULCC (9.14x7.49)
- Description: MOSFET N-CH 100V 8A 18ULCC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANSR2N7261U Specifications:
- MfrPart.: JANSR2N7261U
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 100V 8A 18ULCC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tray
- Series: Military, MIL-PRF-19500/601
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 8A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 12V
- RdsOn(Max)@IdVgs: 185mOhm @ 8A, 12V
- Vgs(th)(Max)@Id: 4V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 50 nC @ 12 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 25W (Tc)
- OperatingTemperature: -55°C ~ 150°C
- MountingType: Surface Mount
- SupplierDevicePackage: 18-ULCC (9.14x7.49)
- JANSR2N7261U Microchip, MOSFET N-CH 100V 8A 18ULCC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
