JANSR2N3700UB Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: 4-SMD, No Lead
- Description: RH SMALL-SIGNAL BJT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANSR2N3700UB Specifications:
- MfrPart.: JANSR2N3700UB
- Mfr: Microchip Technology
- Description: RH SMALL-SIGNAL BJT
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tray
- Series: Military, MIL-PRF-19500/391
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 10nA
- DCCurrentGain(hFE)(Min)@IcVce: 50 @ 500mA, 10V
- Power-Max: 500 mW
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Surface Mount
- Package/Case: 4-SMD, No Lead
- JANSR2N3700UB Microchip, RH SMALL-SIGNAL BJT, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
