JANSR2N3700 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-206AA, TO-18-3 Metal Can
- Description: NPN TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANSR2N3700 Specifications:
- MfrPart.: JANSR2N3700
- Mfr: Microchip Technology
- Description: NPN TRANSISTOR
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/391
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 10 nA
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 10nA
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
- Power-Max: 500 mW
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-206AA, TO-18-3 Metal Can
- JANSR2N3700 Microchip, NPN TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANSR2N3700, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
