JANS2N5004 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-210AA, TO-59-4, Stud
- Description: TRANS NPN 80V 5A TO-59
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANS2N5004 Specifications:
- MfrPart.: JANS2N5004
- Mfr: Microchip Technology
- Description: TRANS NPN 80V 5A TO-59
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/534
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 5 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 1.5V @ 500mA, 5A
- Current-CollectorCutoff(Max): 50µA
- DCCurrentGain(hFE)(Min)@IcVce: 70 @ 2.5A, 5V
- Power-Max: 2 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Stud Mount
- Package/Case: TO-210AA, TO-59-4, Stud
- JANS2N5004 Microchip, TRANS NPN 80V 5A TO-59, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANS2N5004, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
