JANS2N3501 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AD, TO-39-3 Metal Can
- Description: TRANS NPN 150V 0.3A TO-39
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANS2N3501 Specifications:
- MfrPart.: JANS2N3501
- Mfr: Microchip Technology
- Description: TRANS NPN 150V 0.3A TO-39
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/366
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 300 mA
- Voltage-CollectorEmitterBreakdown(Max): 150 V
- VceSaturation(Max)@IbIc: 400mV @ 15mA, 150mA
- Current-CollectorCutoff(Max): 10µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-205AD, TO-39-3 Metal Can
- JANS2N3501 Microchip, TRANS NPN 150V 0.3A TO-39, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
JANS2N3501, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
