JANS1N5822US Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: SQ-MELF, B
- Description: SCHOTTKY DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JANS1N5822US Specifications:
- Manufacturer Product Number: JANS1N5822US
- Mfr: Microchip Technology
- Detailed Description: SCHOTTKY DIODE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/620
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io): 3A
- Voltage - Forward (Vf) (Max) @ If: 500 mV @ 3 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: -
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: SQ-MELF, B
- Operating Temperature - Junction: -65°C ~ 150°C
- JANS1N5822US Microchip, SCHOTTKY DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
