JAN2N7370 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-254-3, TO-254AA (Straight Leads)
- Description: TRANS NPN DARL 100V 12A TO254
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N7370 Specifications:
- MfrPart.: JAN2N7370
- Mfr: Microchip Technology
- Description: TRANS NPN DARL 100V 12A TO254
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/624
- PartStatus: Active
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 12 A
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 3V @ 120mA, 12A
- Current-CollectorCutoff(Max): 1mA
- DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 6A, 3V
- Power-Max: 100 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-254-3, TO-254AA (Straight Leads)
- JAN2N7370 Microchip, TRANS NPN DARL 100V 12A TO254, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
