JAN2N6770 Images
- Manufacturer: Microchip
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-204AE (TO-3)
- Description: MOSFET N-CH 500V 12A TO204AE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
JAN2N6770 Specifications:
- MfrPart.: JAN2N6770
- Mfr: Microsemi Corporation (Now part of Microchip Technology)
- Description: MOSFET N-CH 500V 12A TO204AE
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: Military, MIL-PRF-19500/543
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 500mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 120 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 4W (Ta), 150W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-204AE (TO-3)
- JAN2N6770 Microchip, MOSFET N-CH 500V 12A TO204AE, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
JAN2N6770, Microchip authentic parts in stock from Microchip authorized distributors, order today, can ship immediately.
